Secure the child

Adjust seat height

Before seating the child in the car seat, make sure the seat height corresponds to the stature of the child according to the Seat height adjustment guide (V).

To adjust the car seat, pull and lift the lumbar support (C) upwards to open the hatch in the seat. Adjust the seat upwards or downwards by holding the seat adjustment handle (K) and activating the seat adjustment button (L).

After adjusting the seat height, verify that the height setting corresponds to the stature of the child. Close the hatch and fold back the lumbar support (C).

Restrain the child

Seat the child in the car seat and extend the seat belt. After passing the seat belt over the child, both the lap-and shoulder belt must be routed under the lower belt guide (Q) on the opposite lower side of the car seat. Connect the vehicle seat belt to the belt buckle.

Check seatbelt placement

Make sure the shoulder belt is routed over the middle of the child's shoulder. If not, the headrest needs to be adjusted.

To adjust the headrest height, push the headrest adjustment button and slide the headrest (A) upwards or downwards.
